08 / 29Machinery
Continuous Freezer
Continuously freezes and aerates ice cream mix.
- Capacity
- 200 LPH, 400 LPH, 600 LPH to Max.
- Power Supply
- 415 Volt / 50 Hz / AC, 3 Phase
- Body Material
- SS 304 Food Grade (8% Nickel)
Features
- 01High-conductivity metal hard chrome-plated cylinder
- 02Hollow two-piece construction dasher
- 03Variable-speed AC frequency drive for mix pump
- 04SS diaphragm sanitary pressure gauge
- 05Suction and discharge pressure gauges
- 06Interlock and safety controls
- 07Anti-freeze protection device
- 08SS 304 covering panel
- 09Hot gas supply to freezing cylinder for viscosity control
- 10Hour meter
Technical Specifications
- Capacity
- 200 LPH, 400 LPH, 600 LPH to Max.
- Power Supply
- 415 Volt / 50 Hz / AC, 3 Phase
- Power Consumption
- 5.8 kW/h
- Compressor
- DANFOSS
- Cylinder
- Brass with hard chrome plating
- Gear Box Motor
- Crompton / Equivalent, 2 HP / 1.5 kW
- Refrigerant
- R-404a
- Body Material
- SS 304 Food Grade (8% Nickel)
