14 / 29Machinery
Servo HMI Pouch Packing Machine
Automatically fills and seals pouches.
- Product Dimension
- As per product - 99/62 mm
- Output
- 50 to 120 pouch/min, variable speed
- Sealing Type
- Centre sealing
Features
- 01Low maintenance and easy access
- 02Advanced servo motor control
- 03High-speed wrapping efficiency
- 04User-friendly HMI touchscreen
Technical Specifications
- Product Dimension
- As per product - 99/62 mm
- Output
- 50 to 120 pouch/min, variable speed
- Sealing Type
- Centre sealing
- PLC
- Delta / Equivalent
- HMI
- Fuji / Wecon
- AC Drive
- Crompton / Equivalent
- Photo Sensor
- Banner
- Encoder
- Autonics / Baumer / Equivalent
- Machine Body
- SS Covering
- Power Connection
- 3 Ph / 1 Ph
- Power Requirement
- 2 HP / Heater - 2 × 125W, 4 × 125W
- Main Motor
- 1 HP with 1 HP AC Drive
- Machine Dimension
- 3600 × 1500 × 2000 mm
- Machine Weight
- 400 to 500 kg
- Dosing System
- Manual Filling
